grinding length 600 mm grinding width 300 mm table load 420 kg weight of the machine ca. 2500 kg --> Table magnet size: 600 x 300 mm --> Grinding wheel size: 355 x 38 mm --> Crossbeam: 750 x 340 mm --> Maximum workpiece weight: 420 kg --> Maximum height from table to spindle centre: 500 mm --> Feed rate: 0.3 – 25 m/min --> Spindle motor power: 3.7 kW Pjbin R Esw Dvkao Dujpw --> Machine dimensions: 2730 x 1910 x 1800 mm
Includes vertical height display, cross travel display, automatic downward pull display, hydraulic movement
--> Accessories Various grinding wheels --> Documentation --> Coolant system --> Electromagnetic chuck
